- Model designator (SF) RL
- Wheel size 29"
- Travel (mm) 100mm
- Damper Type Motion Control
- Fork offset 44mm (29")
- Maxle included Maxle Stealth
- Color (FS) Gloss Black
- E-MTB Decal Yes
- Steerer 1.5" Tapered
- Axle 15x110mm BOOST™
- Axle to Crown (mm) 517
- Brake type (FD) Disc
- Crown Material Forged, pocketed aluminum
- Upper crown type n/a
- Lower leg type Magnesium
- Upper Tube Finish Fast Black
- Upper tube type 35mm straight wall aluminum
- Damper adjust Crown
- Damping adjustments Extl rebnd, low speed comp to lock
- Volume reducer 1/2 Tokens
- Spring DebonAir
- Spring rate n/a
- Max Tire Diameter (mm) 768
- Max Tire Width (mm) 81
- Maximum Rotor Size 220mm
- Minimum Rotor Size 180mm
- Fender Compatibility Full or Short, 3 point and 2 point mounts
- Crown OD (mm) 61
- Part Weight (g) 2341
