- Model designator (SF) Ultimate
- Wheel size 29"
- Travel (mm) 180mm
- Damper Type Charger 2.1 RC2
- Fork offset 42mm (29")
- Maxle included Maxle Stealth
- Color (FS) BoXXer Red
- E-MTB Decal No
- Steerer 1.5" Tapered
- Axle 15x110mm BOOST™
- Axle to Crown (mm) 591
- Brake type (FD)Disc
- Crown Material Forged, hollow aluminum
- Upper crown type n/a
- Lower leg type Magnesium
- Upper Tube Finish Fast Black
- Upper tube type 35mm tapered wall aluminum
- Damper adjust Crown
- Damping adjustments Extl begin stroke rebnd, low speed comp, high speed comp
- Volume reducer 0/4 Tokens
- Spring DebonAir
- Spring rate n/a
- Max Tire Diameter (mm) 770
- Max Tire Width (mm) 81
- Maximum Rotor Size 220mm
- Minimum Rotor Size 180mm
- Fender Compatibility n/a
- Crown OD (mm)59
- Part Weight (g)1994
